SMC Networks ZSE30 Series User Manual

Load
Load
Brown DC (+)
Black OUT1
Blue DC (–)
FUNC
White OUT2
+
–
12 to
24 VDC
Load
Load
Brown DC (+)
Black OUT1
Blue DC (–)
FUNC
White OUT2
+
–
12 to
24 VDC
Load
Load
Brown DC (+)
Black OUT1
Blue DC (–)
FUNC
+
–
12 to
24 VDC
White OUT2
Load
Load
Brown DC (+)
Black OUT1
Blue DC (–)
FUNC
+
–
12 to
24 VDC
White OUT2
Main circuit Main circuit
Main circuit Main circuit
Max. 28 V, 80 mA
Residual voltage 1 V or less
Analog current output
Max. load impedance:
Power supply voltage 12 V: 300 Ω
Power supply voltage 24 V: 600 Ω
Min. load impedance: 50 Ω
Max. 80 mA
Residual voltage 1 V or less
Analog current output
Max. load impedance:
Power supply voltage 12 V: 300 Ω
Power supply voltage 24 V: 600 Ω
Min. load impedance: 50 Ω
Max. 28 V, 80 mA
Residual voltage 1 V or less
Analog voltage output
Output impedance: Approx. 1 kΩ
Max. 80 mA
Residual voltage 1 V or less
Analog voltage output
Output impedance: Approx. 1 kΩ
NPN (1 output) + Analog voltage output
C
PNP (1 output) + Analog voltage output
E
NPN (1 output) + Analog current output
D
PNP (1 output) + Analog current output
F
∗ The FUNC terminal is connected using a dedicated lead wire (ZS-38-5L or ZS-38-U) when the copy function is used. (Refer to “Copy function” on page 10.)
5
Series ZSE30A
(
F
)
/ISE30A
2-Color Display
High-Precision Digital Pressure Switch
