8
4 PRODUCT CHARACTERISTICS
4.1 Overall dimensions for built-under installation
R
BACK PANEL
E
ELECTRICITY SUPPLY CABLE
C
FILLER HOSE
P
PERISTALTIC PUMP HOSES
Q
EARTH TERMINAL
S
DRAIN HOSE
T
EXTERNAL DISPENSER POWER SUPPLY CABLE ENTRY POINT
