Instructions for the installer
8.4 Ventilation
The illustrations below show two examples of installation suitable for proper ventilation and one example
of incorrect installation to be avoided.
Do not obstruct the ventilation grille in front of the product in any type of installation.
8.5 Hob seal
To prevent leakage of liquid between the frame of
the hob and the work surface, place the seal
provided along the entire outer edge of the hob
before assembly.
Do not fix the hob using silicone as this would make it impossible to remove the hob, if necessary,
without damaging it.
8.6 Fixing using brackets
Fix the hob to the unit using the appropriate brackets supplied.
To secure the hob correctly to the counter top, tighten the
brackets A in the appropriate holes on the sides of the casing.
Take care while securing with the brackets; if tightened too much the glass may be strained causing it to
crack.
