Smeg SNZ91MFA1 - Page 8

Instructions for the Installer
10
3.2 Burner and Nozzle Data Tables
Burner
Nominal
heat
capacity
(kW)
LPG (PROPANE) – 2.75 KPa
Nozzle
diameter
1/100 mm
By-pass
mm
1/100
Reduced
heat capacity
(W)
Flow rate
g/h G30
Flow rate
g/h G31
Auxiliary 1 50 30 350 73 71
Semi-rapid 1.75 65 33 450 127 125
Rapid 3 85 45 800 218 214
Triple Flame 4.2 66/66/46 * 60/30 1600 305 300
Triple Flame -
internal auxiliary
0.9 46 30 350 73 71
Oven 3.2 87 48 850 233 229
Maxi oven 5.2 110 59 1200 378 371
Grill 2.9 87 // // 218 214
Maxi grill 4.0 100 // // 291 286
*= the identical nozzles are the external ones. The smallest diameter nozzle is the central one
Burner
Nominal
heat
capacity
(kW)
NG – 2.0 KPa
Nozzle diameter
1/100 mm
Reduced heat capacity
(W)
Auxiliary 1 72 350
Semi-rapid 1.75 97 450
Rapid 3 115 800
Triple Flame 4.5 102/102/70 * 1600
Triple Flame -
internal auxiliary
1.0 70 350
Oven 3.2 130 850
Maxi oven 5.2 164 1200
Grill 2.9 130 //
Maxi grill 4.0 150 //
*= the identical nozzles are the external ones. The smallest diameter nozzle is the central one
