Smith SPS8 - Page 20

SPS8
SMITH Manufacturing 1-800-653-9311 www.SmithMfg.com
20
1/2009
ILL# P/N Oty. Description
1 65012 1 Adj. Handlebar Extension (opt.)
   2 65013  2 ScrewAssem.(incl.inP/N:65012)
3 14023 1 Ball Knob
4 10608 2 Hand Grip
5 1050010 1 Corded Engine Kill Button
6 68055 1 Engine Meter (opt.)
7 10127 1 Drive Screw
8 10808 2 Grease Fitting, Straight
9 65009 1 Handle Bar Assembly w/ Cam Lever
9A 1065009.50A 1 Handle Bar Assembly
(incl. ILL# 1, 9B,9C)
9B 1065009.50 1 Handle Bar less Cam Lever Assembly
9C 1010608 1 Foam Grips (set of 2)
9D 65009.25 1 Cam Lever
9E 65009.25A 1 Cam Lever Assembly
(incl. ILL# 3, 8, 9D)
10 10816 4 Cap Screw, 3/8-16 x 1
11 80007 1 Decal
12 14023 1 Ball Knob
13 65019 1 Hand-Wheel w/ Acme Rod
14 10346 1 Socket Head, Cap Screw, 1/2-13 x 4-1/2
15 150550 1 Sleeve, brass
16 85005 1 Bearing
17 110073 2 Flat Washer, 5/8
18 79035 3 Rubber Bushing
19 110359 1 Cap Screw, 5/8-11 x 3-1/4
20 65007 1 Upper Linkage
21 110096 1 Locking Collar, 5/8
22 65006 1 Lower Linkage
23 10339 1 Cap Screw, 1/2-20, x 4
   24 10205  1 LockNut,1/2-20
25 65004 1 Fork
26 65005 2 Spacer, Wheel
27 52001 2 Wheel, 4” (opt. 5” wheel available)
28 110360 2 Cotter Pin, 3/16 x 1-1/2
29 65015 1 Cap Screw, 1/2-13 x 8
30 10312 1 Flat Washer, 1/2
   31 10407  1 LockNut,1/2-13
32 65003 1 Belt Cover
32A 65022.1 1 Hole Plug, Small
32B 65022 1 Hole Plug, Large
   33 10422  2 AcornNut,1/2-13
34 10045 2 Lock Washer, 1/2”
35 10312 2 Flat Washer, 1/2”
   36 10072  2 Nut,1/2-13
37 65016 2 Tube Spacer
38 65017 2 Cap Screw, 1/2-13 x 5
   39 822.25.0 9 NYLock,1/4-20
41 10834 7 Hex Bolt, 1/4-20, 1/2
42 10835 2 Hex Bolt, 1/4-20, 3/4
43 65036 1 Brushes, Set of 4
44 52001 2 Wheel, 4”
45 10428 2 Locking Collar, 3/4
46 65014 1 Axle Shaft
47 10304 2 Cap Screw, 1/2-20 x 1
48 110045 2 Lock Washer, 1/2
49 10312 2 Flat Washer, 1/2
50 65001 1 Main Frame
52 10811 2 Lock Washer, 3/8
53 10025 2 Flat Washer, 3/8
54 65021 1 2” Cap Plug, Vacuum
55 10816 2 Cap Screw, 3/8-16 x 1
56 10802 2 Carriage Bolt, 3/8-16 x 1
57 65002 1 Engine Mount
58 110025 2 Flat Washer, 3/8
   59 10004  2 LockNut3/8-24
60 80001 1 Serial Plate
61 10129 2 Drive Screw
Please note that
due to improvements
and changes in the
equipment, the
illustrations shown
may be different than
the actual machine.
FRAME ASSEMBLY
