Smith SPS8 - Parts List

SPS8
SMITH Manufacturing 1-800-653-9311 www.SmithMfg.com
26
1/2009
Parts List
Electric Motor & Drive Belt Assembly (optional)
ILL# P/N Oty. Description
1 SPSE-0103 1 (Optional) Plug Connector, Locking 20A/250V
2 SPSE-0111 1 Plug, Locking 20A/250V
3 SPSE-0110 1 Power Cord, 10/4 x 60” LOA
  4 FS2E-0101-2 2 ControlBoxConnector,StrainRelief1/2”NPTwithLockNut
   FS2E-0102-2 1 MotorConnector,StrainRelief,3/4”NPT
  5 FS2E-0112-2 1 ConduitLockNut,Motor,3/4”NPT
6 SPSE-0109 1 Starter w/ push button station, motor overload and control relay
6.1 SPSE-0131 1 Overload Relay (380 VAC) (optional)
6.2 SPSE-0132 1 Contactor (380 VAC)
6.3 SPSE-0134 1 Overload Relay (380 VAC)
6.4 SPSE-0104 1 E-Z Stop Switch (all)
6.5 SPSE-0105 1 On/Off Label (all)
6.6 SPSE-0106 1 On/Off Push Button Contacts (all)
6.7 SPSE-0108-2 1 On/Off Push Button Station (all)
6.8 FS2E-0108-2 1 Sub Plate (all)
6.9 SPSE-0102 1 Connector, Cord
7 110018 4 Hex Bolt, 1/4-20 x 3/4
8 10602 8 Washer, Flat, 1/4”
9 10038 4 Washer, Lock, 1/4”
  10 822-25.0 4 NYLock,1/4-20
11 SPSE-0116 2 Mounting Bracket, control box
12 PKB005 4 Hex Bolt, 1/4-20 x 2-1/2”
13 SPSE-0110 1 Power Cord, 10/4 x 60”
14 SPSE-0100-5-3 1 Motor, 5 HP, 3 phase, 380 VAC
SPSE-0100-3 3 HP, single phase, 220V
SPSE-0100.5 5 HP, 3 phase, 208/230/460
SPSE-0100-5-1 5 HP, single phase, 115/208-230
  15 10861  4 HexNut,1/4-20
16 10801 4 Washer, lock, 1/4”
17 10213 8 Washer, Flat, 1/4”
18 SPSE-0118 4 Bolt, Carriage, 5/16-18 x 1
  19 10307  1 Key,1/4”SQx1-3/4”(includedwithmotor)
20 10553 1 Sheave, 4V3x x 1-1/8” Bore, 2.56” O.D.
21 81007 2 Belt, AX33
SPSE-0114 2 Belt, AX31 (380 VAC)
SPSE-0115 1 Belt, 3VX335
22 65018 1 Sheave, 4.12” OD 4V3x SH
23 10505 1 Bushing, Sheave, SH 7/8” ID
24 10115 1 Key, 3/16” Sq x x1 1/2”
