Accessories
SPIKER LIFT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 13-357 Hydraulic Cylinder 1
HNJ-34-16 Jam Nut
3
/
4
- 16 1
2 13-366 Cylinder Extension 1
3 13-382 Cylinder Lift Frame 1
4 13-658 Right Pivot Bracket 1
5 13-659 Left Pivot Bracket 1
6 HB-12-13-150 Bolt
1
/
2
- 13 x 1
1
/
2
4
HW-12 Washer
1
/
2
4
HWL-12 Lockwasher
1
/
2
4
HN-12-13 Nut
1
/
2
- 13 4
INSTALLATION INSTRUCTIONS
1. To mount Spiker onto the Super Rake you must remove the rake lift.
2. You have to unhook the speed boss arm before removing the rake lift. Completely remove the rod speed
limiter and ball joint from machine. The speed boss does not need to function when using the Spiker.
3. Set the spiker behind the machine. Bolt the Spiker to the main frame using the outside holes on the pivot
brackets (Ref 4 & 5). Use the
1
/
2
- 13 x 1
1
/
2
bolts, washers, lockwashers and nuts (Ref 6).
4. Thread the cylinder extension (Ref 2) so it is just on the cylinder (Ref 1). Tighten down with jam nut.
5. Using the first hole from the end of the cylinder extension, hook the cylinder extension (Ref 2) to the
cylinder tab on the cylinder lift frame (Ref 3).
6. Compression springs should be tightened to 6
1
/
2
" for best result.
7. Test spiker for ground penetration. If there is too much ground penetration loosen the springs. If you need
more ground penetration, tighten springs.
The speed boss is not used with spiker. Leave unhooked.
