87
Accessories
13-298 FAN RAKE ATTACHMENT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 13-310 Rake 5
2 13-306 Frame 1
3 HB-38-16-100 Bolt
3
/8 - 16 x 1 4
HN-38-16 Nut
3
/8 - 16 4
HWL-38 Lockwasher
3
/8 4
4 HCP-12-450 Clevis Pin
1
/2 x 4
1
/2 1
5 HHP-18 Bridge Pin
1
/8 1
6 19-107 Drawbar 1
7 HP-18-100 Cotter Pin
1
/8 x 1 1
8 HCP-12-150 Clevis Pin
1
/2 x 1
1
/2 1
9 13-307 Hitch 2
10 HNCL-14-20 Center Lock Nut
1
/4 - 20 5
11 HB-14-20-200 Bolt
1
/4 - 20 x 2 5
FAN RAKE ATTACHMENT INSTRUCTIONS
1. Remove the complete rake assembly from the trap rake. Replace the clevis pin and bridge pin in the hitch
for future use with the rake.
2. Assemble (Ref# 9) Hitch to (Ref# 2)Frame using (Ref# 3)Hardware. Assemble (Ref# 6)Drawbar to the hitch
using (Ref# 4)Clevis Pin and (Ref# 7)Cotter Pin, as shown. The Different Holes in the hitch are for adjust-
ing the angle of the rakes.
3. Assemble the five (Ref# 1) Rakes to the (Ref# 2) Frame using
1
/4 - 20 x 2 bolt and center lock nuts (Ref#
10 and 11). Slide the fan rake assembly under the rear of the trap rake to the hitch. Attach the (Ref# 6)
Drawbar to the hitch using the (Ref# 8) Clevis Pin and the (Ref# 5) Bridge Pin.
4. Hook the chains from the Frame to the hooks on the Rake Lift.
