Introduction
SPECIFICATIONS
WEIGHTS AND DIMENSIONS
Length with Rake 85" (216cm)
Width with Rake 73.5" (187cm)
Height 44" (112cm)
Wheel Base 47" (119cm)
Crated Weight 990 lbs (449kg)
SOUND LEVEL (DBA) AT 3200 RPM
At ear level 84 dba
At 3 ft (0.914 m) 89 dba
At 30 ft (9.14 m) 74 dba
ENGINE
Make Briggs and Stratton Vanguard
Model# 303447
Type / Spec# 1018A2
Horsepower 16 Hp (12 Kw)
Fuel Unleaded 85 Octane Gasoline Minimum
Cooling System Air Cooled
Lubrication System Pressure type
Alternator 16 amp
WHEELS & TIRE (3) 21 x 11.00 x 8 NHS 5 psi (0.35bar)
SPEED
Forward Speed 0 to 10 mph (0-16 kph)
Reverse Speed 0 to 4 mph (0-6 kpk)
BATTERY (Not Included) Automotive type 45-12 volt
BCI Group Size 45
Cold Cranking Amps 480
Ground Terminal Polarity Negative (-)
Maximum Length 9" (23cm)
Maximum Width 5.38" (14cm)
Maximum Height 9" (23cm)
FLUID CAPACITY
Crankcase Oil Approximately 1.5 quart (1.4 liters) without filter
Approximately 1.75 quart (1.7 liters) with filter
Fuel 15.6 quart (14.8 liters)
Hydraulic Fluid 12.9 quart (12.2 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or higher
OPTIONAL EQUIPMENT
13-413 Front Mounted Sand Plow 42-128 72" Stainless Steel Tournament Rake
13-644 Sand Plow, Aluminum Blade 13-298 Fan Rake Attachment
13-412 Hydraulic Plow (factory installed) 34-191 Box Grader
13-505 Attachment Lift (13-551 only) 34-190 Spiker
13-395 Front Mount Fan Rake 26-007 Professional Infield Finisher
13-107* Infield Scarifier 26-008 Flex Action Field Finisher
13-116* Weed Cultivator 13-111 Drag Mat Kit
13-199* Edger Kit 42-550 Green Star Total RBS System
13-438 Rake Assembly 42-503 RBS Mount for Smithco Super Rake
13-606 Rake Assembly with Lexan Blades 42-530 22-11.00 x 8 Turf Track R/S Tire
42-026 84" Stainless Steel Tournament Rake 42-531 22-11.00 x 8 Custom Smooth Tread Tire
* Must have 13-505 Lift Assembly installed before installation (13-551 Only).
