15
Diagrams
HYDRAULIC DIAGRAM
REF# PART# DESCRIPTION QUANTITY
1 13-032 Wheel Motor 1
2 13-424 Hydraulic Hose (63
1
/4 long) 1
8840-62 Flex Guard Loom 1
3 13-425 Hydraulic Hose (70
1
/4 long) 1
8840-69 Flex Guard Loom
4 13-409 On - Off Valve 1
18-174 Elbow
1
/2 ST Thread 2
18-228 Hollow Hex Plug 2
18-266 Elbow 45° 2
5 13-587 Hydraulic Hose (16 long) 1
6 13-584 Oil Tank 1
13-586 Filler Breather 1
7 8810-11 Hose
5
/8 1
18-077 Hose Clamp 2
8 13-616 Hydraulic Hose (29 long) 1
9 8810-36 Hose
5
/8 1
18-077 Hose Clamp 2
10 13-110 Hydrostatic Pump 1
11 23-006 Oil Filter 1
23-031 Replacement Filter Only
12 8917-11 Suction Hose
5
/8 1
18-077 Hose Clamp 2
13 18-184 Hydraulic Hose (29 long) 1
14 13-617 Hydrauic Hose (25 long) 1
15 13-615 Wheel Motor 2
16 13-612 Hydraulic Tube 2
17 23-172 Oil Cooler 1
18 13-633 Hydraulic Hose (19
1
/2 long) 2
18-264 Cap (2WD only) 2
19 18-164 Hydraulic Hose (16 long) 2
20 13-292 Hydraulic Cylinder 1
21 13-357 Hydraulic Cylinder 1
22 13-552 Hydaraulic Hose (21
1
/4ong) 1
23 13-549 Hydraulic Hose (24
1
/8 long) 1
24 76-105 Hydraulic Hose (17
1
/2long) 1
25 13-261 Hydraulic Valve (2 bank) 1
13-262 Valve Handle Set (2 bank) 1
13-355 Hydraulic Valve (3 bank)
13-484 Valve Handle Kit (3 bank)
26 60-368 Hydraulic Hose (59
1
/4long) 1
27 13-406 Hydraulic Cylinder 1
28 13-444 Hydraulic Hose (50 long) 1
