Smithco 13-550-C - Page 23

21
Parts
MAIN FRAME PARTS LIST
REF# PART# DESCRIPTION QUANTITY
20 HB-38-16-125 Bolt
3
/8 - 16 x 1
1
/4 2
HW-38 Washer
3
/8 2
HNTL-38-16 Lock Nut
3
/8 - 16 2
21 13-637 Engine Mount 1
22 13-214 Battery Hold Down 1
8900-6 Flex Guard Loom
1
/4 1
HWL-14 Lockwasher
1
/4 2
HNW-14-20 Wing Nut
1
/4 - 20 2
23 13-213 Battery Box 1
HB-516-18-100 Bolt
5
/16 - 18 x 1 4
HW-516 Washer
5
/16 6
HNTL-516-18 Lock Nut
5
/16 - 18 4
24 13-099 Hose Clamp 1
HB-38-16-175 Bolt
3
/8 - 16 x 1
3
/4 1
HNTL-38-16 Lock Nut
3
/8 - 16 1
25 13-218 Mud Guard 1
HB-38-16-125 Bolt
3
/8 - 16 x 1
1
/4 3
HW-38 Washer
3
/8 4
HNTL-38-16 Lock Nut
3
/8 - 16 3
26 22-054 Battery Cable 1
HB-38-16-125 Bolt
3
/8 - 16 x 1
1
/4 1
HW-38 Washer
3
/8 1
HWL-38 Lock Washer
3
/8 1
HN-38-16 Nut
3
/8 - 16 1
