Smithco 13-550-C - Page 57

55
Accessories
13-413 HYDRAULIC SAND PLOW WITH LIFT PARTS LIST (DEALER INSTALLED)
13-412 HYDRAULIC PLOW WITH LIFT PARTS LIST (FACTORY INSTALLED)
REF# PART# DESCRIPTION QUANTITY
2 13-325 Brace 1
HB-38-16-100 Bolt
3
/8 - 16 x 1 1
HW-38 Washer
3
/8 4
HNCL-38-16 Center Lock Nut
3
/8 -16 3
3 13-407 Cylinder Bracket 1
4 15-013 Rubber Bumper 2
5 13-168 Left Pusher Bar 1
6 13-352 Hydraulic Sand Plow 1
7 13-322 Lift Bar 1
8 HCP-12-200 Clevis Pin
1
/2 x 2 1
HHP-18 Bridge Pin
1
/8 1
9 HB-38-16-125 Bolt
3
/8 -16 x 1
1
/4 2
HW-38 Washer
3
/8 2
HWL-38 Lockwasher
3
/8 2
HN-38-16 Nut
3
/8 -16 2
10 HB-38-16-100 Bolt
3
/8 -16 x 1 4
HWL-38 Lockwasher
3
/8 4
HN-38-16 Nut
3
/8 -16 4
11 13-167 Wear Blade 1
12 HB-12-13-300 Bolt
1
/2-13 x 3 2
HWL-12 Lockwasher
1
/2 2
HN-12-13 Nut
1
/2 - 13 2
13 HB-38-16-225 Bolt
3
/8 -16 x 2
1
/4 4
HW-38 Washer
3
/8 4
HNCL-38-16 Center Lock Nut
3
/8 - 16 4
14 13-169 Right Pusher Bar 1
15 HCP-12-150 Clevis Pin
1
/2 x 1
1
/2 2
HHP-18 Bridge Pin
1
/8 2
16 HB-38-16-250 Bolt
3
/8 -16 x 2
1
/2 (part of Trap Rake) 2
HWL-38 Lockwasher
3
/8 (part of Trap Rake) 2
HN-38-16 Nut
3
/8 -16 (part of Trap Rake) 2
17 13-406 Hydraulic Cylinder 1
14-267 Seal Kit 1
23-141 Union Adapter 1
HNJ-58-18 Jam Nut
5
/8 - 18 1
23-018 O-ring Elbow 1
13-324 Ram Extension 1
