Smithco 13-550-C - Page 75

73
Accessories
13-111 DRAG MAT KIT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HHP-18 Bridge Pin
1
/8 1
2 Hitch (Part of Trap Rake) 1
3 Rake Lift (Part of Trap Rake) 1
4 HB-38-16-225 Bolt
3
/8 - 16 x 2
1
/4 4
HWL-38 Lockwasher
3
/8 4
HN-38-16 Nut
3
/8 - 16 4
5 13-195 Left Mat Carrier Post 1
6 19-605 Drag Mat Chain 1
7 19-601 Drag Mat 1
8 13-156 Right Mat Carrier Post 1
9 13-157 Carrier Lock Strap 2
13-112 Carrier Kit, posts with hardware 1
INSTALLATION INSTRUCTIONS
1. Looking from the rear of the trap rake, mount the (Ref# 8) Mat Carrier Post outside the right rear corner of
the rake lift with the (Ref# 9) Lock Strap on the inside of the rake lift side plate. Bolt into place with two
(Ref# 4) bolts, nuts and lockwashers.
2. Mount the (Ref# 5) Left Mat Carrier outside the left corner similar to the right side with the (Ref# 9) Lock
Strap to the inside.
3. To carry the Mat, roll it up and place it in the brackets of the Carrier Posts.
4. To use the mat, unroll it flat and hook it up to the trap rake hitch with the clevis pin and bridge pin.
