13-438 RAKE ASSEMBLY WITH FINISHING BLADES PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 13-441 Right Rake 1
2 HMB-58-14 Machine Bushing
5
/
8
x 14GA 2
3 HNCL-58-11 Lock Nut
5
/
8
- 11 2
4 HMB-12-14 Machine Bushing
1
/
2
x 14GA 11
5 HP-18-100 Cotter Pin
1
/
8
x 1 3
6 13-440 Center Rake 1
7 13-443 Finishing Blade 5
8 13-439 Left Rake 1
9* 19-106 Rake teeth 25
10 13-442 Groomer Blade 3
11 HCP-12-150 Clevis Pin
1
/
2
- 1
1
/
2
3
12 13-365 Drawbar 1
13 HB-58-11-400 Bolt
5
/
8
- 11 x 4 2
14 HSSQS-38-16-200 Stainless Steel Square Head Set Screw
3
/
8
-16 x 2 2
HNS-38-16 Stainless Steel Nut
3
/
8
- 16 2
15 HHP-18 Bridge Pin
1
/
8
1
16 13-647 Hitch (includes Ref 14) 1
17 HCP-12-450 Clevis Pin
1
/
2
- 4
1
/
2
1
18 13-417 Connector Link 10
* 13-445 Rake Teeth Kit
(25 Studs and Hardware) 1
INSTALLATION INSTRUCTIONS
1. Attach drawbar (Ref 12) to hitch (Ref 16) using clevis pin, machine bushing and cotter pin (Ref 17, 4 and 5).
2. Bolt rake teeth (Ref 9) to frames, keeping all the same length. Leave the two outside holes on right and left rake
open (Ref A).
3. Lay out rake frames (Ref 1,6 and 8). Connect them using clevis pin, machine bushing and cotter pin (Ref 11, 4
and 5).
4.
Attach drawbar to left and right frames using bolt, machine bushing, and nut (Ref 13, 2 and 3).
5. Attach five finishing blades (Ref 7) to the tabs of the rake frames using master link (Ref 18). Blades may be
mounted with saw tooth up or down, depending on the desired finish of the sand trap.
6. Attach the rake hitch (Ref 16) to trap rake hitch on the rear axle using a clevis pin and bridge pin (Ref 11 and 15).
7. The end links of chain on the drawbar are to be hooked to the hooks of the trap rake lift.
8. With the rake on the ground pull the rake to the right side until it is 2-3 inches from the tire.
9. Using the adjustment screw (Ref 14) on the right, adjust the screw until it hits the trap rake hitch, located on rear
axle. Lock jam nut so adjustment will not change.
10. Repeat steps 8 and 9 on left side.
11. Turn machine on and test for operation of rake assembly by raising and lowering the rake assembly. Also with
rake down, turn sharp corners to check that rake does not touch wheels.
12. NOTE: Test rake in sand to assure tire tracks are covered by the rake when turning sharp corners in either
direction. If there are tire tracks, readjust using the adjusting screws on the hitch, so the rake comes closer to
the tire.
GROOMER BLADES - GOLF COURSE USE ONLY.
1. Place the three groomer blades (Ref 10) under the three rake assemblies (Ref 1, 6 and 8) .
2. Center blades below rear most row of rake teeth. The blade is designed to miss the outside two “teeth’ and fit
around the center ‘tooth’.
3. Remove the two ‘teeth’ that line up with slots of each groomer blade. Move blade up and into position and
reattach ‘teeth’. Blade thickness should be accounted for by shortening the ‘teeth’ an equal length.
