Accessories
26-007 PROFESSIONAL INFIELD FINISHER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 Rake Holder (Part of Trap Rake) 1
2 Rake Lift (Part of Trap Rake) 1
3 HP-18-100 Cotter Pin
1
/8 x 1 1
4 HCP-12-150 Clevis Pin
1
/2 x 1
1
/2 1
5 HB-58-11-300 Bolt
5
/8 - 11 x 3 2
HNCL-58-11 Center Lock Nut
5
/8 - 11 2
6 13-365 Drawbar 1
7 26-045 Leveling Screen 1
8 HCP-12-450 Clevis Pin
1
/2 x 4
1
/2 1
9 HMB-12-14 Machine Bushing
1
/2 x 14GA 1
10 19-107 Hitch 1
11 HHP-18 Bridge Pin
1
/8 1
INSTALLATION INSTRUCTIONS
The Professional Field Finisher is used for smoothing and leveling fields to professional standards.
1. Attach (Ref# 7) Leveling Screen to (Ref# 6) Drawbar using two (Ref# 5)Bolts and Center Lock Nuts.
2. Attach (Ref# 10) Hitch to (Ref# 6) Drawbar using (Ref# 8)
1
/2 x 4
1
/2 Clevis Pin, (Ref# 9)
1
/2 x 14GA Machine
Bushing and a (Ref# 3)
1
/8 x 1 Cotter Pin.
3. Mount Professional Field Finisher to the hitch on the trap rake with a (Ref# 4)
1
/2 x 1
1
/2 Clevis Pin and
(Ref# 11)
1
/8" Bridge Pin.
4. Hook chains from Finisher to Rake Lift Arms.
5. NOTE: When assembled properly, rake will angle down from front to back. If front of finisher is not higher
than the back, damage will result to infield.
