Diode Test
Test Current Over Load Protection
1.5mA MAX 500 V DC or AC RMS
Continuity Buzzer
Test Voltage Threshold Over Load Protection
3V <35W 500 V DC or AC RMS
Non-Contact Voltage (NCV)
Detection Range: 24VAC and above
Temperature (K-Type thermocouple)
Range Res. Accuracy
-30˚F to 1000˚F 0.1˚F +
(1˚F) 32.0˚F to 120˚F
(˚F Version) +
(1%+1.5˚F) -30˚F to 750.0˚F
+
(2%+4˚F) -30˚F to -4˚F
+
(2%+4˚F) 750˚F to 1000˚F
-35˚C to 600˚C 0.1˚C +
(1˚C) 0˚C to 48.9˚C
(˚C Version) +
(1%+1˚C) -19.9˚C to -0.1˚C
+
(1%+1˚C) 49.0˚C to 399.9˚C
+
(2%+3˚C) -35˚C to -20˚C
10
Warning: Use only correct type and overvoltage
category rated test leads. Remove the
temperature probe when using the test
leads or amp clamp.
