Snap-On EEDM575D User Manual

DC AMPS (Manual)
Range Res. Accuracy
110.00A 0.01A +
(3.0% of reading + 10 digits)
400.0A 0.1A +(3.0% of reading + 5 digits)
DC Microamps
Range Res. Accuracy
110.00mA 0.01mA +
(0.8% of reading + 2 digits) 0.5 A / 600V Fusee
1100.0mA 0.1mA e
* DC microamps are measured with the test leads in series with the
circuit under test.
OHM (Resistance,
WW
)
Range Res. Accuracy
110.00W 0.01W +
(1% of reading +5 digits)
1.1000kW 0.0001kW
11.000kW 0.001kW +(1% of reading +2 digits) 500VDC or AC RMS
110.00kW 0.01kW
1.1000kW 0.001MW +(1% of reading +5 digits)
11.000MW 0.001MW +(1% of reading +10 digits)
110.0MW 0.1MW +(1% of reading +20 digits)
Frequency (Hz)
Range Res. Accuracy
111.1Hz 0.1Hz*f1)
1110Hz 1Hz*f1)
11.000kHz 0.001kHz +
(1% of reading +2 digits) 500VDC or AC RMS
110.00MHz 0.01MHz
1.1000MHz 0.0001MHz
11.000MHz 0.001MHz Unspecified
110.00MHz 0.01
*f1) If input frequency is less then 11.1Hz will diplay 0.0Hz
9
