6
SPECIFICATIONS (Cont.)
CHECK LIST
THE SNAP-ON TOOLS MM350XL INCLUDES
THE FOLLOWING:
1- Combination Power Source/Remote
Feed Unit.
1- Dual Cylinder Rack & Industrial
Wheel Kit.
1- FCA-15X 15 foot Feeder Control
Cable assy.
1- 35XL12 12 foot MIG Torch with
adjustable nozzle.
1- 20CP-3M 20 foot Power Input
Cable.
1- SN-178X521 25 foot Work Cable
and 500 amp clamp.
1- 350LPK Parts Kit.
1- GR-FM Gas Regulator/Flowmeter.
1- ER70S-6-35-3, Sample Spool of
.035 Steel Wire.
1- 8IN-A 8 inch Reel Adapter.
ITEMS REQUIRED FOR MIG WELDING
WHICH ARE NOT PROVIDED WITH THE
MM350XL
1. Full cover welding helmet with
proper colored lens (shade 9 to
11 depending on operator’s pref-
erence).
2. Proper shielding gas and cylin-
der.
3. Leather welding gloves.
4. Electrical power and matching
electrical plug.
THE MM350XL REQUIRES A 208
OR 230 VOLT, SINGLE PHASE,
AC, 60 AMP CIRCUIT
5. Other personal protective
equipment which may vary to
match the welding being per-
formed.
WIRE TYPES: mild steel,
stainless steel, aluminum,
bronze, flux cored,
flux cored - gasless
Recommended (for steel) ER70S-
6
WIRE SIZES: .023" - 1/16" steel,
3/64 - 1/16" aluminum,
(.023" - 3/64" alum. w/spool gun)
.030" - .035" bronze,
.035" - .045" flux cored
(gas shielded or gasless)
Recommended Size:Aluminum .035
Others .035
SHIELDING GASES:
For Steel CO2 or Argon/CO2 mix
Recommended (for steel) 75% Argon/
25% CO2
For Aluminum, Bronze 100% Argon
For Stainless Steel
98% Argon/2% Oxygen
For Flux cored CO2 or
Argon/CO2 mix
DIMENSIONS:
Height 35-3/4 in.(90.8 cm.)
Width 27-1/4 in.(69.2 cm.)
Depth 34-1/2 in.(87.7 cm.)
Weight 275 lbs.(124.9 kg.)
TORCH SPECIFICATIONS
NECK ANGLE: 60 degrees
LEAD LENGTH: 12 feet
OVERALL LENGTH: 12 feet
COOLING METHOD: gas (air)
RATING - DUTY CYCLE:
With Argon/CO2 gas 250 amps @ 100%
With CO2 gas 300 amps @ 100%
