Snap-On PLASMA 20i User Manual

10
When ordering spare parts please always state the machine item and serial number and its purchase data, the spare
part position and the quantity.
POS PART N. DESCRIPTION
01
CKS5811009
HOUSING
02
CKSP3002
HANDLE SUPPORT
03
CKS5803995
HANDLE
04
CKSP3004
RING NUT
05
CKS5803539
REGULATOR SUPPORT
06
CKSB7014380
GAUGE
07
CKSB7006380
REGULATOR
08
CKSP3008
FITTING
09
CKSP3009
SWITCH
10
CKSP3010
COVER
11
CKS5580273
POWER CORD
12
CKSB7018380
CABLE OUTLET
13
CKSB5812733
BACK PANEL
14
CKSTI3008
FRAME
15
CKS3160195
SOLENOID VALVE
16
CKSP3032
PRESSURE SWITCH
17
CKSP3021
UNION ELBOW
18
CKS3160141
FITTING
19
CKS3160035
FITTING
20
CKS3160026
FITTING
21
CKS5710562
AIR UNIT
22
CKS5803179
AIR UNIT SUPPORT
23
CKS3115078
RUBBER FOOT
POS PART N. DESCRIPTION
24
CKS5811636
BOTTOM
25
CKSP3024
TERMINAL BOARD
26
CKSP3025
STRAIN RELIEF WITH NUT
27
CKSP3028
STRAIN RELIEF
28
CKS5585014
CABLE WITH CLAMP
29
CKSP3029
KNOB
30
CKS5812330
FRONT PANEL
31
CKS5602544
POWER CIRCUIT
32
CKS260453
MOTOR WITH FAN
33
CKS5803180
CIRCUIT SUPPORT
34
N/A
TORCH CABLE
35
CKSP3040
TORCH CONNECTOR
36
CKSP3041
HANDGRIP WITH PUSHBUT-
TON
37
CKS251194
O.RING
38
PLASMA 2006
TORCH BODY (HEAD)
39
PLASMA 2003
SWIRL RING (PACK. 2 PCS.)
40
PLASMA 2004
ELECTRODE (PACK. 5 PCS.)
41
PLASMA 2002
NOZZLE (PACK. 5 PCS.)
42
PLASMA 3001
NOZZLE HOLDER
43
PLASMA 2007
COMPLETE TORCH
44
CKSP6021
PFC CHOKE
45
CKSP6020
CHOKE SUPPORT
