Snap-On TPMS4 User Manual

TPMSCONNECT
CONNECT USB DRIVE TO PC
CONNECT TPMS4 TO PC
14
Setting / (UPDATE)
G
USB Jump Drive TPMSconnect
The USB jump drive is used to install the TPMSconnect portal and also includes TPMS4 User's
manual. Insert the USB Jump Drive into the PC or Laptop USB port and follow the on-screen in-
structions. This will provide the user with initial product registration and it will also bring the TPMS4
to the most current software version. After the first 12-months the purchase of TPMS4U update
will allow software updates for a 12-month time period.

Snap-On TPMS4 Specifications

General

Display	Color LCD
Battery	Lithium-ion
Connectivity	Bluetooth, USB
Operating System	Proprietary
Compatibility	Compatible with most vehicles equipped with TPMS
Operating Frequency	315 MHz, 433 MHz
Update Method	USB
Functions	TPMS sensor activation, programming, diagnostics
