Snap-On TPMS4 User Manual

6
Directional
Buttons
Test
Button
Antenna
Power
(On/ Off)
Button
Enter
No / Cancel
Button
N
USB
USB Jack SD Card Slot
RJ45 Jack
SD
RJ45
Chapter 1: Introduction
TPMS diagnostic tool that tests tire pressure monitoring sensors, captures sensor data and
relearns tire pressure monitoring systems. Also programs aftermarket sensors and prints
sensor information
.
Battery
Replacement
Screws*
Included Power Adaptors
Battery Replacement
Bottom View
Kit Contents
TPMS4
Diagnostic Tool
TPMS3-4
USB Cable
TPMS4-7
AC/DC Power Adapter
TPMS4-9
Soft Carry Case
TPMS4-10
TPMSconnect USB
Jump Drive
* Torque to 0.26 – 0.43 in-Lb
Nylon Soft Case

Snap-On TPMS4 Specifications

General

Brand	Snap-On
Model	TPMS4
Category	Diagnostic Equipment
Language	English
