Snapmaker A250 - Assemble the CNC Carver

18
3.1 Assemble the CNC Carver
Attach the CNC Module to the Slider. Connect the CNC Module to the Controller from the behind of the X Axis, and
lock the Toolhead cable into the Cable Holder. Leave enough length for the Toolhead to move.
Turn off the machine before assembly. Do not connect or disconnect any cables when the machine is turned on.
M4 × 8 Hex Socket
Head Screw × 4
Toolhead Cable × 1
Controller × 1
CNC Module × 1
