3.4.4 Attach the CNC Bit
How It Works: Straight Groove V-bit
The Straight Groove V-bit features a long and sharp carving edge, penetrating deep into materials and rendering high-precision creations. The extended
flutes on both sides create a larger area of engagement, providing a superior carving than single flute bits. It can also clear swarf, eliminating clogging
and reducing wear and tear.
L1
D1
A
L
D
Total Length (L) Flute Length (L1) Shank Dia (D) Cutting Dia (D1)
50 mm 24 mm 3.175 mm 0.3 mm 20 °
Side Angle (A)
