Quick Start Guide
|
21
1
1
2
2
M4 x 8 Screw x 12
Linear Module x 2
08
/22
Thread the connecting cables through the holes of the holders, and then attach
the Z axes to the Z-axis Holders. Do not tighten the screws until Step 12.
