Quick Start Guide
|
33
Add-on 3 Heated Bed Power
Screen
USB
Toolhead Add-on 1 Add-on 2
X axis
Y axis
Z axis
20
/22
Open the dust plugs, and then connect the X, Y and Z axes with the Controller.
Keep the protective dust plugs
on the unplugged slots. Dust
accumulation may seriously
affect the performance of the
Controller.
Make sure the connectors are in the right direction.
To Next Page
