Snapmaker Ray - Tips and Notes for Assembly

8
|
Before You Start
1.4 Tips and Notes for Assembly
It is recommended that at least two people lift the
machine and the Enclosure.
Collect and sort the cables in time lest anyone
should trip over them.
Do NOT press the steel strip.
To install multiple screws in one step:
1. Pre-tighten the screws at the outermost corner;
2. Pre-tighten the remaining screws;
3. Tighten all the screws in the pre-tightening
order.
* Pre-tighten: To screw the screw into the hole, yet not
fully tighten it.
To install screws with the provided hex key:
1. Screw the screw into the hole with the long
handle;
2. Tighten the screw with the short handle.
