52
|
Assembling the Enclosure
01
/29
Identify two short beams (without any LED strips) and attach four profile
connectors to both ends of the beams.
Screw Number Screwdriver
M5 × 12 4 H3.0
Profiles rank by length: long beam > short beam > column.
Make sure the alignment tabs of the profile
connectors are inside the profile grooves.
You need to pay attention to this detail also in
subsequent similar steps.
