Assembling the Enclosure
05
/29
Insert one of the front/back panels, the left side panel, and the right side
panel into the frame.
Make sure the edges of all panels are inserted into the grooves of the
corresponding profiles. You need to pay attention to this detail also in
subsequent similar steps.
Make sure the opening for the exhaust fan is positioned near the back
panel with the snap bushing opening located beneath.
