11
DIFFERENTIAL, R. H. FENDER
ITEM PART NO. DESCRIPTION
1 1-4401* COLLAR, Lock (Includes P.N. 9-0201, 5/16-18 x 5/16” Setscrew)
2 1-8822* BALL BEARING, Axle (Right Hand Fender)
2A 1-2296 BEARING, Axle (Right Hand Fender) (standard bearing)
3 1-0969 NUT, 5/16-24 Hex Flange Lock
4 3-1079 WASHER, Thrust
5 3-8067 PLATE, Differential
6 2-2115 SPACER, Pinion (4)
7 2-1127 GEARS, Differential Pinion (4)
8 1-1072 WASHER, Thrust
9 5-1584 ASSEMBLY, Drive Hex Tube
10 1-0988 WASHER, Hex Nylon Splash (3)
11 1-0964 GEAR, 11 Teeth-10 Pitch
12 1-0941 CHAIN, 46 Pitch (No. 35)
13 2-1129 SPROCKET
14 1-0965 RING, External Retaining
15 2-1128 SPACER
16 1-2332 CLAMP, Boot (2)
17 1-7083 BOOT, Oil Seal
18 1-1024 PLUG, Oil Fill & Check
19 3-7279 CASE, Transmission
20 2-8762 GASKET, Transmission Case
21 3-7280 FENDER, Right Hand (standard fender) (1.62” hole)
-- 3-7957 FENDER, Right Hand (optional fender) (2.498” hole)
22 2-1158 GEAR, 63 Teeth-10 Pitch
-- 2-7644 GEAR, 63 Teeth 10 Pitch (331522KVE Model only)
23 4-7763 AXLE, Long (Includes Gear) (Use Only With Short Axle P.N. 5-7398)
24 7-4431 SPACER
25 5-7398 AXLE, Short (Includes Gear) (Use Only With Long Axle P.N. 4-7763)
26 1-2333 SCREW, 5/16-24 x 1-5/8" Hex Cap Special Lock (4)
27 1-1156 O-RING, 5/16” (2)
28 1-1782 WASHER, 5/16” Belleville (2)
29 9-0395 WASHER, 5/16” External Tooth Lock
30 9-0188 WASHER, 5/16” Flat
31 1-1042 BOLT, 5/16-24 x 2-5/8" Idler
32 9-0361 SCREW, 5/16-18 x 5/8" Hex Washer Self-Tap (11)
33 9-0362 SCREW, 1/4-20 x 5/8" Hex Washer Self-Tap (13)
34 3-2107 SPACER, Short Axle
35 6-1017 GREASE, Transmission (24 oz. Required)
-- 6-0411 KIT, Differential (Includes 2A & 3-7280 Fender)
-- 6-0662 KIT, Differential (Includes items 2 & 3-7957 Fender)
*Optional Ball Bearing may be used (requires use of 3-7957 fender
R. E. RIDER SERIES 22 MANUAL No. 06128
