Snapper 301022BE

27
THROTTLE CONTROL
ITEM PART NO. DESCRIPTION
1 2-2751 CONTROL, Throttle (23.6” long) (Briggs Engines)
-- 7-4320 CONTROL, Throttle (34.6” long) (Kohler Engine)
2 9-0539 SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap (2)
3 3-3470 PLATE, Throttle Control
4 9-0913 SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Torx) (2)
R. E. RIDER SERIES 22 MANUAL No. 06128
4
3
2
1
