HARDWARE BAGS
ITEM PART NO. DESCRIPTION LOCATION
-- 6-1872 HARDWARE BAG (includes items listed below)
1 1-1024 PLUG, Oil Fill & Check (2) ................................................page 11, item 18 &
page 13, item 14
2 1-3321 BUSHING, Tie Rod (2)......................................................page 7, item 12
3 1-3849 SPACER, 21/64” (2) .......................................................... page 25, item 10
4 1-3862 PIN, 1/4 x 1-1/2” Roll ......................................................... page 6, item 3
5 2-3191 KNOB, Three Prong (2)..................................................... page 25, item 9
6 2-3667 FOAM COVER, Steering Shaft ......................................... page 6, item 23
7 2-3671 COVER, Steering Shaft..................................................... page 7, item 32
8 2-8395 SPACER, Pivot (2) ............................................................ page 7, item 33
9 2-9211 SEAT SWITCH, Quick Mount ........................................... page 25, item 13
10 9-0372 NUT, 1/4-20 Hex Center Lock (2) ..................................... pg. 32 & 34, item 24
11 9-1038 BOLT, 5/16-18 x 1/2” Hex Flange Lock (2) ....................... page 25, item 12
12 9-1516 PIN, 5/32 x 1” Cotter (2) .................................................... page 3, item 11
page 7, item 41
13 9-0296 PIN, 3/16 x 1” Cotter ......................................................... page 7, item 24
14 9-0122 WASHER, 3/8” Flat (2)...................................................... page 7, item 6
15 9-0913 SCREW, #10-24 x 1/2” Hex (Torx) (2)..............................page 7, item 43
ITEM PART NO. DESCRIPTION LOCATION
-- 6-3185 HARDWARE BAG (includes items listed below)
1 1-1024 PLUG, Oil Fill & Check (2) ................................................page 11, item 18 &
page 13, item 14
2 1-3321 BUSHING, Tie Rod (2)......................................................page 7, item 12
3 1-3849 SPACER, 21/64” (2) .......................................................... page 25, item 10
4 1-3862 PIN, 1/4 x 1-1/2” Roll ......................................................... page 6, item 3
5 2-3191 KNOB, Three Prong (2)..................................................... page 25, item 9
6 2-3667 FOAM COVER, Steering Shaft ......................................... page 6, item 23
7 2-3671 COVER, Steering Shaft..................................................... page 7, item 32
8 2-9211 SEAT SWITCH, Quick Mount ........................................... page 25, item 13
9 9-0372 NUT, 1/4-20 Hex Center Lock (2) ..................................... pg. 32 & 34 item 24
10 9-1038 BOLT, 5/16-18 x 1/2” Hex Flange Lock (2) ....................... page 25, item 12
11 9-1516 PIN, 5/32 x 1” Cotter (2) .................................................... page 3, item 11 &
page 7, item 41
12 9-0296 PIN, 3/16 x 1” Cotter ......................................................... page 7, item 24
13 9-0122 WASHER, 3/8” Flat (2)...................................................... page 7, item 6
14 9-0913 SCREW, #10-24 x 1/2” Hex (Torx) (2)..............................page 7, item 43
MANUAL No. 06128 R. E. RIDER SERIES 22
