42” CUTTING DECK ASSEMBLY (page 2 of 4)
ITEM PART NO. DESCRIPTION
1 4-2645 WELDMENT, 42” Deck
2 5-1401 ASSEMBLY, Side Chute (Includes Decal, Item 14)
3 5-9628 ASSEMBLY, Spindle (2)
4 2-6691 BLADE, 21” Standard Lift (2)
5 1-4168 SPRING, Belt
6 1-2055 ROD, Idler
7 3-8021 MOUNT, Handle
8 4-6874 GRIP, Handle
9 5-3034 ASSEMBLY, Spindle Ring (2)
10 2-9264 WHEEL, Gage (4)
11 3-5835 POST, Anti-Scalp (4)
12 2-9265 BOLT, Gage Wheel, 3/8-16 x 3-3/8” Hex Head Shoulder (4)
13 1-4852 DECAL, Caution
14 2-6831 DECAL, Danger
15 9-0613 NUT, 3/8-16 Hex Flange Lock (6)
16 9-1508 BOLT, 5/16-18 x 3/4” Short Neck Carriage, Grade 5 (4)
17 2-9303 STAND-OFF, 3-1/2” long, 5/16-18 top, 3/8-16 bottom threads (2)
18 9-0613 NUT, 3/8-16 Hex Flange Lock (6)
19 5-9254 WELDMENT, Blade Engage Lever
20 9-0299 SCREW, #10-32 x 1” Hex Washer Self-Tap, Grade 2
21 1-8524 SWITCH, Deck Interlock (NO)
22 9-0055 WASHER, 1/4” Flat
23 9-0037 PIN, 3/32 x 3/4” Cotter
24 1-2063 WASHER, Cone (4)
25 9-0824 SCREW, 3/8-24 x 1” Hex Head Cap, Grade 5
26 1-2670 RING, Tolerance (2)
27 1-4526 SPACER (2)
28 1-1791 RETAINER, 5/16” Bolt (2)
29 9-1537 WING-NUT, 5/16-18 Lock (2)
30 9-1296 WASHER, 5/16” Flat (2)
31 9-1585 NUT, 3/8-16 Hex Center Lock (4)
32 9-1049 WING-NUT, 3/8-16 Nyloc (4)
33 9-1328 SCREW, 3/8-16 x 1-1/4” Hex Head Cap, Grade 5 (4)
34 4-6567 HANDLE, Blade Engagement
35 9-1974 PIN, 3/16 x 1” Clevis
36 4-6648 SPRING, Torsion
37 9-0555 PIN, 3/32 x 1/2” Cotter
38 9-0362 SCREW, 1/4-20 x 5/8” Hex Washer Self-Tap (2)
NOTE: DECK ASSEMBLY IS CONTINUED ON THE FOLLOWING TWO PAGES.
42” MODEL R. E. RIDER SERIES 22 MANUAL No. 06130
