23
DRIVE DISC A
SSEMBLY
ITEM
PA
RT NO.
DESCRIPTIO
N
1
7-2658
W
ELDMENT
, 5.75” O. D. Drive Disc
2
9-0132
SCREW
, 3/8-
16 x 3/8" Set (2)
3
1-0210
KEY, 1/4” Square x 2”
42” M
ODEL R. E. RIDER SERIES 22
MANUA
L
No. 06130
3
2
1
22
24
Table of Contents
Table of Contents
1
Description
2
Wheels- Tires
2
Front End, Steering
4
Main Case
6
Main Case
7
Differential, R. H. Fender
8
Chain Case, L.h. Fender
10
Smooth Clutch Assembly
12
Rails, Lift Arms, Cam Lift
14
Cutting Deck, Deflector
16
Deck Cover, Belts, Blade Brakes
20
Deck Cover, Belts, Blade Brakes
21
Description
21
Spindle Assembly
22
Drive Disc Assembly
23
Fuel Tank & Operator's Seat
24
Exhaust Muffler, Engine
24
Throttle Control
25
Electrical System
26
Wiring Schematic
28
Decals
29
Decals
31
Mower Series
32
