19
42” CUTTING DECK ASSEMBLY
(page 4 of 4)
ITEM PART NO. DESCRIPTION
39 -- ASSEMBLY, Rail (See Pages 14 & 15 for Parts Breakdown)
40 7-3267 PEDAL, Blade Stop Control
41 3-4758 ARM, Idler
42 2-8200 SWIVEL, Adjustable (with 5/16-18 internal thread)
43 7-3217 CLIP, Cable
44 1-5448 SPRING, Pedal
45 9-0606 BOLT, 5/16-18 x 5/8” Hex Flange Lock (5)
46 1-0740 RING, 2” External Retaining (4)
47 2-9244 EYE-BOLT, 5/16-18 x 3”
48 9-1503 HAIRPIN, 3/32 x 1-1/2”
49 9-0585 NUT, 5/16-18 Hex Flange Lock (5)
50 9-0289 NUT, 3/8-24 Hex Center Lock
51 1-4795 WASHER, 2” I. D. Nylon (2)
52 1-5446 BOLT, 3/8-24 x 9/16” Shoulder
53 9-0250 WASHER, 1/2” Flat (3)
54 2-4341 SPRING, Return
55 7-4649 SPRING, Latch
56 9-1514 WASHER, 3/8” Flat
57 3-4754 SPRING BRAKE PAD
58 9-0583 NUT, 1/4-20 Hex Flange Lock
59 9-0584 BOLT, 1/4-20 x 1/2” Hex Flange Lock (2)
60 2-8786 BUSHING, 3/8” Snap Plastic
61 7-6978 NUT, 1/4-20 Hex Nyloc
62 2-8754 LINK, Spindle Brake
63 9-0673 PIN, 1/16 x 1/2” Cotter
64 9-1776 BOLT, 1/4-20 x 3/4” Round Head Square Neck, Grade 5
65 9-1576 NUT, 1/4-20 Hex, Grade 5 or B
NOTE: DECK ASSEMBLY IS CONTINUED FROM THE PREVIOUS THREE PAGES.
42” MODEL R. E. RIDER SERIES 22 MANUAL No. 06130
