9
DIFFERENTIAL, R.H. FENDER
ITEM PART NO. DESCRIPTION
1* 5-4372 ASSEMBLY, R.H. Fender Bearing & DX Bearing
2 9-0362 SCREW, 1/4-20 x 5/8" Hex Washer Self-Tap (13)
3 3-1079 WASHER, Thrust
4 1-0969 NUT, 5/16-24 Hex Flange Lock
5 3-8067 PLATE, Differential
6 2-2115 SPACER, Pinion (8)
7 2-1127 GEARS, Differential Pinion (8)
8 1-1072 WASHER, Thrust
9 5-1584 ASSEMBLY, Drive Hex Tube
10 1-0988 WASHER, Hex Insert
11 1-0964 GEAR, 11 Teeth-10 Pitch
12 1-0941 CHAIN, 46 Pitch (#35)
13 2-1129 SPROCKET
14 1-0965 RING, 1-13/16” External Retaining
15 2-1128 SPACER
16 1-2332 CLAMP, Boot (for 2” Hose) (2)
17 1-7083 BOOT, Oil Seal
18 1-1024 PLUG, Oil Fill & Check
19 3-7279 CASE, Transmission
20 2-8762 GASKET, Transmission Case
21* 3-7280 FENDER, Right Hand
22 2-7644 GEAR, 63 Teeth-10 Pitch
23 4-7763 AXLE, Long (Includes Gear)
(Use Only With Short Axle #5-7398)
24 7-4431 SPACER
25 5-7398 AXLE, Short (Includes Gear)
(Use Only With Long Axle #4-7763)
26 1-2333 SCREW, 5/16-24 x 1-5/8" Hex Cap Special Lock (8)
27 1-1156 O-RING, 5/16 (2)
28 1-1782 WASHER, Belleville (2)
29 9-0395 WASHER, 5/16” External Tooth Lock
30 9-0188 WASHER, 5/16” Flat
31 1-1042 BOLT, 5/16-24 x 2-5/8" Idler
32 9-0361 SCREW, 5/16-18 x 5/8" Hex Washer Self-Tap (11)
33 6-1017 GREASE, SNAPPER Transmission (24 oz. Required)
-- 5-7260 ASSEMBLY, Differential (Includes items 5, 6, 7, 23,
24, 25, & 26)
-- 6-0662 KIT, Differential (Incl.1-8822, Ball Bearing & 3-7957, Fender)
-- 6-0411 KIT, Differential (Includes 1-2296, Powdered Metal Bearing for item 1 and
3-7280, Fender)
*NOTE: 5-9203 Cover & Fender Assembly is composed of items 1 & 21.
42” MODEL R. E. RIDER SERIES 22 MANUAL No. 06130
