Snapper 7800104 User Manual

Maintenance
(Continuedl
WARNING
D0
NOT
attempt
any adjustments,
maintenance,
servtce
or
repairs
with
the engine
running.
ST0P engine.
ST0p
blade.
Engage
parking
brake. Remove
key.
Remove
spark
plug
wire
from
spark
plug
and
secure
away from
plug.
Engine
and components
are H0T.
Avoid
serious
burns, allow
all
pafts
to
cool
before working
on machine.
Fuel
Filler
Cap
and vent
must
be closed
securely
to
prevent
fuel
spillage.
Service
-
Every
25
Operating
Hours
(Continued)
Rear
Axle
Bearing
-
Lubrication
'1.
The
grease
fitting (A,
Figure
27)on
the teft
rear
axle
bearing requires
three
shots
of
general purpose
grease
from
grease
gun.
2. fhe
right
rear
axle
bearing is lubricated
by the
differentral
lubricant
and requires
n0
grease.
2. To
check lubricant, remove
the fill/level
plug
and visually
inspect
for lubricant
on the internal
parts
of the
differential.
lf no lubricant
is visible
on the internal
parts
of the differential,
add transmission
grease
as needed.
IMP0RTANT:
Overfilling
of the
differential with
lubricant
will
cause lubricant
to leak
onto
drive components
of the Rear
Engine
Rider.
Figure
28: Differential
lubricant
check
3. Check the
fill/level
plug
(A,
Figure
29)
on the
chain
case
(B)for
damage. lf
signs of wear
or cracks
are visible,
replace
with
a new
plug.
4. To
check lubricant
in the
chain case, remove
the fill/level
plug
and look for
lubricant
on the internal
components
of
the
chain
case. lf no lubricant
is visible.
add
SNAPPER transmission
0rease
as needed.
a
Figure
27: Rear
axle
grease
fitting
Differential
i
Ghain
Gase
-
Lubrication
1.
Stand the
rear
engine rider
on its rear
bumper
and
check the
fill/level
plug
(A,
Figure
28)
on the
differential
(B)
for
cracks
and wear.
Reptace
the
fill/levet
plug
if
signs
of wear
are visible.
IMP0RTANT:
lf
the Rear
Engine
Rider
wiil
be on its
rear
bumper
for longer
than
two hours,
remove
the
battery.
Refer
to
the
section entitled
"BATTERY
REMOVAL".
Figure
29:
Chain case lubricant
check
Engine
Service
Check the MAINTENANCE
SCHEDULE
section
of the Enqine
Manual for
additional
enqine
service.
17
