37
Specifications
ENGINE:
1150 Series Briggs & Stratton
Make Briggs & Stratton
Model Snow Series, M15H
Gross Torque* 11.50 ft-lbs (15.6 Nm) @ 3060 rpm
Displacement 15.3 cu. in (250 cc)
Oil Capacity 20 oz. (,59 l)
CHASSIS:
Wheels
- 1226 Tire Size: 15 x 5
Inflation Pressure: 20 psi (1,37 bar)
Spout Rotation 200 Degrees
Impeller 12 in. (30 cm) 4 Blade Ribbon Flighted Steel
Auger Opening Height 21 in. (53 cm)
Drive System Friction Disc, 6 Forward Speeds, 2 Reverse
DIMENSIONS:
Effective Clearing Width
- 1226 26 in. (66 cm)
Length
- 1226 52.75 in. (134 cm)
Height
- 1226 35.13 in. (89.2 cm)
Weight
- 1226 248 lbs (112 kg)
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive
Engineers) code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been
obtained and corrected in accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM;
horsepower values are derived at 3600 RPM. Actual gross engine power will be lower and is affected by, among
other things, ambient operating conditions and engine-to-engine variability. Given both the wide array of products
on which engines are placed and the variety of environmental issues applicable to operating the equipment, the gas
engine will not develop the rated gross power when used in a given piece of power equipment (actual “on-site” or net
power). This difference is due to a variety of factors including, but not limited to, accessories (air cleaner, exhaust,
charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating conditions (temperature,
humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton
may substitute an engine of higher rated power for this Series engine.
