11
TANDEM HYDRO TRANSAXLE ASSEMBLY
(All Models Except ZM2200K, ZM2500KH)
ITEM PART NO. DESCRIPTION
1 5-4437 ASS’Y, Eaton Transaxle 771B (L.H.) Side (shown)
-- 5-9154 ASS’Y, Eaton Transaxle 771-090 (L.H.) (w/needle bearings)
-- 5-4436 ASS’Y, Eaton Transaxle 771A (R.H.) Side
-- 5-9153 ASS’Y, Eaton Transaxle 771-089 (R.H.) Side (w/needle bearings)
2 9-1514 WASHER, 13/32 I.D. x 13/16 O.D. Flat (4)
3 9-1299 NUT, 3/8-16, Hex Nyloc (4)
4 7-2017 SPACER, Eaton Transaxle (8)
5 9-1995 SET SCREW, 5/16-18 x 5/16” Square Head (4)
6 4-6967 PULLEY, Transmission (Right Hand) 4.95” Diameter (2)
7 9-1786 BOLT, 3/8-16 x 4-3/4” Hex Flange, Grade 5 (4)
8 9-1787 SCREW, 1/4-20 x 5/8”, Hex Flange Lock, Grade 5 (8)
9 4-6966 PULLEY, Transmission (Left Hand) 4.95” Diameter (2)
10 2-7223 WASHER, 1/4 Split Lock (4)
11 9-1814 SCREW, 1/4-20 x 1-1/4”, Hex Head Cap (3)
12 9-0505 SCREW, 1/4-20 x 2”, Hex Head Cap, Grade 5
13 9-1603 NUT, 1/4-20 Hex Nyloc (8)
14 4-3897 FAN, Blade 7” Dia. (2)
15 9-1627 WASHER, 1/4 I.D. x 1” O.D. (2)
16 4-2639 CAM, Neutral Return (Weldment) (2)
17 3-5910 PLATE, Neutral Adjust (2)
18 1-2709 RETAINING RING, 1” External (2)
19 2-7175 BOLT, 5/16-18 x 2-1/2” Hex Head (2)
20 3-5915 SPRING, Neutral Return Adjust (2)
21 3-5927 SPRING, Neutral Return (2)
22 9-1812 NUT, 1/4-28, Hex Nyloc (4)
23 1-4264 WOODRUFF KEY, #404 (2)
24 5-9440 ASSEMBLY, Driveshaft Bracket
25 9-1315 WASHER, 21/64” Split Lock (6)
26 9-1904 SCREW, 5/16-18 x 7/8”, Hex Head Cap (6)
27 5-4293 PLATE, Neutral Return (Weldment)
28 1-5753 BALL-JOINT 1/4-28 Thread (4)
29 9-1605 NUT, 1/4-28 Hex, Grade 5 or B (4)
30 4-4755 ROD, Threaded 1/4-28 x 6-5/8”
31 3-5914 ROD, Threaded 1/4-28 x 5-3/8”
32 1-5894 WOODRUFF KEY, #605 (2)
33 4-5184 FILTER, Oil (Eaton)
34 3-5925 ROD, Roll Release (2)
35 9-1629 COTTER-PIN, 1/16 x 1/2” (2)
NOTE: HYDRO TRANSXALE MAINTENANCE SHOULD ONLY BE PERFORMED
BY AN AUTHORIZED SNAPPER DEALER.
MID MOUNT Z-RIDER MANUAL No. 06110
