45
SEAT ASSEMBLY
(Except for MZM2200K & MZM2300KH)
ITEM PART NO. DESCRIPTION
** 5-4117 SEAT ASSEMBLY (Includes indented items below)
1 ** PAN, Complete
2 3-6476 CUSHION, Seat
3 3-6477 CUSHION, Back
4 4-4724 BRACKET, Armrest (Right Hand
5 3-5568 BRACKET, Armrest (Left Hand)
6 3-6478 CHANNEL, Armrest
7 3-6479 ARM PAD, Grey (2)
8 3-6484 ADJUSTER (with lock)
9 3-6485 ADJUSTER (without lock)
10 ** STUD GUARD (4)
11 3-6486 SPACER, Bell (4)
12 9-1296 WASHER, 5/16” Flat (8)
13 9-1601 NUT, 5/16-18 Hex Flange Lock, Grade 5 (6)
14 ** SCREW, 1/4-20 x 3/4” Phillips (9)
15 ** SCREW, #8-32 x 1/2” Self Tapping (2)
16 2-7174 SCREW, 5/16-18 x 2” Hex Head Cap, Grade 5 (2)
17 3-5797 WASHER, 13/32” I.D. x 3/4 O.D. Poly (4)
18 9-1067 NUT, 5/16-18 Hex Head Center Lock, Grade B (2)
19 9-0646 SCREW, 1/2-13 x 1” Hex Head Cap, Grade 5 (2)
20 9-0975 NUT, 1/2-13 Hex Head Center Lock, Grade 5 (2)
21 9-0683 SCREW, 5/16-18 x 1” Slotted Pan Head
22 4-2968 HOLDER, Beverage
23 4-4902 SPACER, Cup Holder
24 4-4903 COVER, Cup Holder
25 9-1919 RIVET, 3/16” Pan Head (3)
26 4-4904 BRACKET, Armrest Cup Holder
27 9-1303 BOLT, 5/16-18 x 1” Short Neck Carriage, Grade 5 (6)
**NOTE: Not a Part Sales item.
Refer to pages 26 & 27 for Seat Support Components.
MID MOUNT Z-RIDER MANUAL No. 06110
