ENGINE SUB-ASSEMBLY
ITEM PART NO. DESCRIPTION
1 ** ENGINE, 22HP (Kohler No. CH22S PS-66536)
-- ** ENGINE, 23HP (Kohler No. CH23S PS-76536)
-- ** ENGINE, 25HP (Kohler No. CH25S PS-68577)
2 3-5638 J-CLIP, 3/8” Cushioned (2)
3 9-1523 SCREW, 5/16-18 x 5/8” Hex Washer Self Tap (2)
4 9-1299 NUT, 3/8-16 Nyloc (4)
5 9-1553 SCREW, 3/8-16 x 1-3/4” Hex Head Cap, Grade 5 (4)
6 2-2486 OIL DRAIN, Short
7 2-7972 ASSEMBLY, Oil Valve
8 9-1838 SCREW, M6 x 1 x 6mm Hex Flange Cap (Qty. 2 for 22 HP;
Qty. 4 for 25 HP) (Kohler part no. M-0650012)
9A 4-2708 BRACKET, Muffler, 22HP Kohler
9B 4-6486 BRACKET, Muffler, 25HP Kohler (Series 0)
10A ** MUFFLER, 22HP Kohler (Kohler part no. A-24 068 00)
10B 4-6488 MUFFLER, 25HP Kohler (Kohler part no. A-24 068 17)
11 9-1839 SCREW, M5 x 8 x 16mm Hex Head Self Tapping (2) (Kohler # M-0545016)
12A 4-2707 GUARD, Muffler
12B 7-2155 GUARD, Muffler (used on ZMT2500KH & ZM2501KH models)
13 9-1840 SCREW, M5 x 8 x 10mm Hex Head Flange (2) (Kohler #M0550010)
14A 3-5675 SPACER, Clutch
14B 4-6410 SPACER, Clutch (Model MZM2200KH Only)
15 3-5520 CLUTCH, Electric
-- 4-6409 CLUTCH, Electric (Model MZM2200KH Only)
16 9-1806 SCREW, 7/16-20 x 1-1/2” Hex Head Cap. Grade 5
17 9-1301 WASHER, 7/16” Split Lock (2)
18 9-1807 WASHER, 7/16 I.D. x 1-3/8 O.D. x 1/4 Flat
-- 9-1962 WASHER,7/16” I.D.x 1-5/8” O.D. x 1/4 Flat
19 9-1304 SCREW, 3/8-16 x 1” Hex Head Cap, Grade 5
20 9-1808 SCREW, 7/16-14 x 1”, Grade 5
21A 3-5852 BRACKET, Anti-Rotation (5/16”)
21B 5-8207 BRACKET, Anti-Rotation (Model MZM2200KH Only)
22 4-6487 SHIELD, Heat, 25HP Kohler
23 7-2256 SPACER, Muffler Guard
24 9-2016 SCREW, 1/4-20 x 1-1/2” Hex Washer Self-Tap (2)
25 1-3250 KEY, 1/4 Square x 1”
26 4-6411 BRACKET, Torque
NOTE: Items 2, 3 & 8 thru 13 are included with engine.
MID MOUNT Z-RIDER MANUAL No. 06110
