SnoMaster SM-26 - STRUCTURE; Installation of Water Inlet System

1 Power Switch
2 Display Panel
3 Front Panel
4 Door
5 Ice Grid
6 Ice Storage Bin
7 Ice Full Sensor
8 Power Cord
9 Water Inlet Valve
10 Drainage Outlet
11 Leveling Feet
2 Water Filter Inlet Pipe
1 Tap
3 Water Filter
4 Water Filter Outlet Pipe
5 Water Inlet Valve
6 Drain Outlet
(Drain Outlet Must Be 100mm
Lower Than The Appliance)
INSTALL THE WATER INLET
SYSTEM AS FOLLOWS:
07
STRUCTURE
1
2
3
4
5
6
8
9
11
10
7
3
2
4
5
6
1
*Arrows Indicate Direction Of Water Flow
