Repair Parts – 4 S2646/S3246
Item Part No. Qty. Description
Chassis, Steering and Brakes
1 300351 2 BRG THR .500ID .750OD .500
2 300542 2 SNAP RING 1.00 EXT HD
3 300729 20 BLT LUG .500-20 X .72" 60 DEG UNF
4 301442 2 SWIVEL SHORT 90 DEG (-10-6)
5 301443 2 SWIVEL LONG 90 DEG (-10-6)
6 302800 1 LEVEL SENSOR 2 AXIS 2&4
7 330001-1 4 WHEEL-TIRE 16X5 NON-MARKING
8 0361550 1 DIODE WIRE ASSY
9 0371857 1 LINK TIEROD STEERING
10 0371859-0 1 WLMT BASE FRAME
11 0371872 4 HUB 1.50 TAPERED SHAFT
12 0371873-3 1 WLDMT, SPINDLE, STEERING, LF
13 0371874-3 1 WLDMT, SPINDLE, STEERING, RT
14 0371909 1 PLATE, BALLAST
15 0371914 2 PLATE, BALLAST
16 465276 2 PIN CLV .500DIA 1.281 GRIP
17 970029 4 BLT HEXHD .250-20 .75 GR5-Z/P
18 970229 2 BLT HEXHD .313-18 .625 GR5 ZINC PLATED
19 970459 2 BLT HEXHD .375-16 .875- GR4
20 970989 8 BLT HEXHD .500-13 3.50 GR5
21 978549 4 BLT HEXHD .500-13 4.50
22 984069 4 NUT HEX .250-20
23 984149 4 NUT HEX .500-13
24 986019 4 WSHR FLAT .250
25 986299 2 WSHR FLAT .38
26 986359 4 WSHR FLAT .500
27 987099 4 WSHR LOCK .250
28 987109 2 WSHR LOCK .313
29 988179 2 PIN COT .125DIA 1.00-1/8 X 1
30 989509 2 PIN RILL .188 DIA 1.00
31 2580407 2 BRG THR 2.25ID 3.00OD .125
32 2594905 2 BRG 2.25ID 2.44OD 1.75
33 2594907 2 BRG 2.25ID 2.44OD .75
34 5035306 2 FTG ELB90STRTHD-8B-8S STL
35 5037003 2 FTG ELB90SWVL-4S-4S STL
36 5035706 4 FTG ELB45STRTHD-8B-8S STL
37 5065703 2 FTG ADPTR STRTHD-4B-4S STL
38 5065728 4 FTG ADPTR STRTHD-6B-8S STL-PH
39 5093001 2 CLP CUSH .500 VINYL COATED
40 5560033 2 NUT HEX LKG .375-16 ESNA
41 5560039 16 NUT HEX LKG .500-13
42 5560668 8 BLT HEXHD .500-13 3.75 GR5
43 5560689 2 BSHG MCHRY 1.00ID 1.50OD 14GA
44 5569964 2 BRG FLG 1.00ID 1.13OD .500
45 6019062 1 MANIFOLD DRIVE SPEED
46 6031615 2 MOTOR WHL 28.3 CU 1.5 TAPER
47 6047108-3 1 CYL STEER 1.50 X 11.92 X.63
48 6091501 2 HYD BRAKE/HUB BK10
101 0021059 2 HOSE-8-8S-8S 40 100R2
102 0110198 4 HOSE-8-8S-8S 96 100R2
