i S2646/3246
About This Manual
This manual covers S2646E/S3246E and S2646/S3246
aerial platforms. Page titles may indicate specific mod-
els or date ranges.
• Some pages are applicable to all models and are
neither model or date specific.
• Some pages are machine specific by model name.
If a page title has only the older conventional model
name, without the E, it is applicable to both conven-
tional and the newer E model machines.
If a page title has only the newer E model name, it is
applicable only to the newer E model machines.
• Some pages are machine specific by date and are
applicable to all models.
Information is included for machines that have been manu-
factured to conform to all applicable requirements of the
following organizations.
• American National Standards Institute (ANSI)
• Canadian Standards Association (CSA)
• European Committee for Standardization (CE)
Parts pages include a drawing and a bill of material. The
bill of material lists the item number that is on the draw-
ing, the Snorkel part number, quantity used, and a de-
scription of the item.
Some pages have callouts in the drawings that have a
balloon with two numbers. The top number is the item
number and the bottom number is the quantity of that
item at that location.
While Snorkel has attempted in every way to confirm
that all information in this manual is correct, improve-
ments are being constantly made to the machine that
may not be reflected in this manual.
If you find information in this manual that is not correct,
or is confusing, you are urged to report your findings to
Snorkel for our evaluation. Your input is important to us
and will be used in future printings of this manual.
General Information
This machine is covered by a limited warranty that spe-
cifically identifies items warrantied by Snorkel and those
items covered by original manufacturers warranty. A copy
of the Snorkel Limited Warranty is located on the inside
of the back cover of this manual.
Repairs and Maintenance
Every person who maintains, inspects, tests, or repairs
the machine must be qualified and authorized to do so.
ACaution
Do not modify this aerial platform without prior writ-
ten consent of Snorkel Engineering Department.
Modification may void the warranty, adversely af-
fect stability, or affect the operational characteris-
tics of the aerial platform.
Abbreviations
The following abbreviations may be used in this manual.
AC alternating current
ANSI American National Standards Institute
CCA cold cranking amps
cm centimeter
DC direct current
GFCI ground fault circuit interrupt
mm millimeters
ft feet
in inch
lbs pounds
no number
NPT national pipe thread
psi pounds per square inch
qty quantity
UL Underwriters Laboratories Inc.
Additional Information
All correspondence relative to this machine, such as field
reports, discrepancy reports, requests for information, etc.,
should be directed to:
Snorkel International, Inc.
P.O. Box 1160
St. Joseph, MO 64502-1160 USA
Phone: 1-800-255-0317
http://www.snorkellifts.com
Refer to the back cover of this manual for the nearest
Snorkel location outside of North and South America.
1
6
