General Specifications
Maximum platform height . . . . . . . . . . . 20¢ (6.1 m)
Working height . . . . . . . . . . . . . . . . . . . 26¢ (7.9 m)
Platform size
Main . . . . . . . . . . 30² x90² (76.2 cm x 228.6 cm)
Extension. . . . . . . . . 24² x36² (61cmx91.4cm)
Platform rated work load
Total. . . . . . . . . . . . . . . . . . . . . . . 800 lb (363 kg)
Platform extension . . . . . . . . . . . . 250 lb (113 kg)
Weight (GVW approx.) . . . . . . . 3,750 lb (1,701 kg)
Drive
Speed #1, elevated . . . . . . . . . 0.4 mph (0.6 kph)
Speed #2, stowed . . . . . . . . . . 1.2 mph (1.9 kph)
Speed #3, stowed . . . . . . . . . . 2.0 mph (3.2 kph)
Gradeability. . . . . . . . . . . . . . . . . . . . . . . . . . . 20%
Platform function speed
Platform raise
Speed #1. . . . . . . . . . . . . . . . . . . . . . . . 85 sec
Speed #2. . . . . . . . . . . . . . . . . . . . . . . . 35 sec
Speed #3. . . . . . . . . . . . . . . . . . . . . . . . 20 sec
Platform lower . . . . . . . . . . . . . . . . . . . . . 42 sec
Turning radius
Inside. . . . . . . . . . . . . . . . . . . . . . . 30² (76.2 cm)
Outside . . . . . . . . . . . . . . . . . . . 101² (256.5 cm)
Overall length . . . . . . . . . . . . . . . . . 91² (231.1 cm)
Overall width . . . . . . . . . . . . . . . . . . . 33² (83.8 cm)
Overall height, stowed . . . . . . . . . 78.5² (199.4 cm)
Guardrail height
Platform . . . . . . . . . . . . . . . . . . . . 41² (104.1 cm)
Platform extension . . . . . . . . . . . . 40² (101.6 cm)
Toeboard height . . . . . . . . . . . . . . . . . 6² (15.2 cm)
Wheelbase . . . . . . . . . . . . . . . . . . . 71² (180.3 cm)
Ground clearance
Pothole protector lowered . . . . . . . 0.75² (1.9 cm)
Pothole protector raised. . . . . . . . . 3.25² (8.3 cm)
Tires
Solid rubber, non-marking . . . . . . . . . . . . 16² x4²
. . . . . . . . . . . . . . . . . . . . . (40.6 cm x 10.2 cm)
Electrical system. . . . . . . . . . . . . . . . . . . . 24 V DC
Hydraulic system
Maximum pressure. . . . . . 2,750 psi (18,961 kPa)
Hydraulic fluid recommended
Above 10° F (-13° C) . . . . . . . . Mobil DTE-13M
Below 10° F (-13° C) . . . . . . . . Mobil DTE-11M
Reservoir capacity
Total . . . . . . . . . . . . . . . . . 6.5 gal USA (24.6 L)
To full mark . . . . . . . . . . . . . 6 gal USA (22.7 L)
Ambient air temperature operating range
Fahrenheit . . . . . . . . . . . . . . . . . . . 0° F to 110° F
Celsius . . . . . . . . . . . . . . . . . . . . -18° C to 43° C
Drive system . . . . . . . . . . . . . . . . . . . 2 wheel drive
Floor loading pressure
Local concentrated pressure . . . . . . . . . . 186 psi
Overall uniform pressure . . . . . . . . . . . . . 213 psf
page 2 - 2 SL 20 – 300206
Chapter 2. Specifications
