Snorkel SL26-01 Series Operating Manual

Chapter 8 – Operation
40 SL30SL – 8210037
7. Replace the upper control panel on the front right
side of the guardrail, and hanging inside the platform.
Refer to Figure 8.11.
y In this position the guardrail and upper control
box arrows will point the same direction, towards
the front of the machine.
Figure 8.11 – Upper Control Operating Position
Right Guardrail
Upper Controls
