SL30SL – 8210037 3
Chapter 2 – Specications
Component Identication
Toeboards
Elevating
Assembly
Right Side
Platform
Front
Left
Guardrail
Rear
Left Side
Entry
Steps
Lower
Controls
Operator’s
Manual
Chassis
Emergency
Lowering Valve
Upper
Controls
Front
Rear
Entry
Gate
Tie-Down/Lifting
Lugs
Tie-Down/Lifting
Lugs
Engine Compartment
Engine • Hydraulic Pump • Battery
Fuel Tank
Hydraulic Compartment
Hydraulic Reservoir • Hydraulic Fluid Filter
Rear Guardrail
Right
Guardrail
Front
Guardrail
