SnowEx Bulk-Pro 1875 - Page 15

© Trynex International 2009 L1040
7 — 15
Wiring Diagram
Model # SP-325
Key Part No. Description Qty.
D 6474 Mini Control 1
D 6486 325 Harness 1
D 6748 25 Amp Breaker 1
(+) Pos.Red
(–) Neg. Black
(–) Neg. Black
(+) Pos.Red
12 VOLT
BATTERY
On/O Switch
Speed Control Knob
SPREADER MOTOR
O o o c l
d c ol d pl c e o
c ld g c c b d d
vo d
Special Notes:
1. All external connections must have dielectric grease.
2. Read lead labels before attaching to power source or ground.
o o ev p o
4. Any repairs to wiring harness must be done with heat
shrink butt connectors.
O o o d f l
d c ll o d
Rev. 05
