CHAPTER 1: INTRODUCTION 9
Status Indicator LED
Bluetooth (Blue)
1 blink per second
Bluetooth radio is on but not connected
1 blink per 3 seconds CHS connected to host device
Good Read (Green) On
Data successfully scanned and transmitted to
host device
On and connected to charger Battery full
Battery (Red) Blinking 20% battery capacity remaining
Off Off or Good Battery status
Status Indicator Beeps
2 beeps (low-high) Power on
2 beeps (high-low) Power off
1 beep CHS connected to host device and ready to scan barcodes.
1 beep (low)
You have double-pressed the power button, and the CHS has
enabled support for simultaneous scanning and onscreen keyboard
entry for Apple iOS
1 beep with green LED (configurable
setting)
Data successfully scanned and sent to host device
2 beeps (same tone) CHS disconnected from host device
1 long beep
CHS unsuccessfully tried 30 times to connect to the last host
device it paired with. The CHS will become discoverable.
5 beeps
The CHS detects an internal fault, will reset and power off. If
connected to a host computer, the scanner will disconnect during
the reset.
