socomec DIRIS Digiware C Series User Manual

36 EN
#(1(2#(&(6 1$ŰŰ$2.".,$"
Description of the terminals
DIRIS Digiware D-40 ',5,6'LJLZDUH''
NC
RS485
Digiware
LIYCY-CY
SLAVE
24 V
SUPPLY
24 VDC
(20 W max)
Digiware
Bus

NC
RS485 Digiware
LIYCY-CY
MASTER
24 VDC
(20 W max)
Ethernet
24 V
SUPPLY
Digiware
Bus
Ethernet

Ű F& LETRDHETRHMF@MNM2.".,$"RTOOKX
DIRIS Digiware C-31
24 V
SUPPLY
RS485
NC
1 2
ON
DIGIWARE BUS
RJ45
24 V
SUPPLY
RS485
NC
LIYCY-CY
1 2
ON
24 V
SUPPLY
RS485
NC
1 2
ON
Digiware BUSPower supply Communication Line polarisation
DIRIS Digiware C-32 DIRIS Digiware U DIRIS Digiware I-3x
DIGIWARE BUS
RJ45
INOUT
24 V
SUPPLY
Digiware BUSPower supply
V1
VN
V3
V2
DIGIWARE BUS
RJ45
Digiware BUSVoltage
measurement
I 01
I 02
I 03
RJ12
DIGIWARE BUS
RJ45
Digiware BUSCurrent measurement
(**)
DIRIS Digiware I-4x DIRIS Digiware I-6x
I 01
I 02
I 03
I 04
RJ12
Current
measurement
(**)
DIGIWARE BUS
RJ45
Digiware BUS
INPUT
1
COM
2
12 Vd.c.(1mA max)
Inputs
OUTPUT
250 Va.c.(1A max)
21
11
13
23
OutputsRJ9
for DIRIS D-30
(Self-powered and
C@S@
RJ9
DIGIWARE BUS
RJ45
Digiware BUSCurrent
measurement
(**)
I 04
I 05
I 06
I 01
I 02
I 03
RJ12 RJ12
 KV@XRBNMMDBSHMOTS(EHQRS
DIRIS Digiware IO-10 DIRIS Digiware IO-20
13
14
23
24
12-48VDC
12-24VAC
50mA
12VDC
IN1
COM-
IN2
IN3
IN4
OUT1
OUT2
OUTPUT
INPUT
,QSXWVRXWSXWV
DIGIWARE BUS
RJ45
Digiware BUS Inputs
DIGIWARE BUS
RJ45
Digiware BUS
