The way the OID is assigned to a device (instance number) is the following:
OID = Main OID (= default 100) + ModbusAddress:
• Device with Main OID (100) is the DIRIS Digiware D-50 / D-70 display itself.
• The device with OID (1xx) is the device with the Modbus address xx.
Analog Input Object:
The DIRIS Digiware D-50 / D-70 acts as a BACnet gateway. It provides a number of Analog Input objects which may be
available from the devices compatible and connected to the DIRIS Digiware D-50 / D-70.
Whether a device supports an AI object depends on its measurement functionalities.
Ex: The OID for THD_I1 will return 0 for a DIRIS Digiware I-30 module because this parameter is not handled.
The AI object denes 25 properties. The devices compatible and connected downstream the DIRIS Digiware D-50 / D-70
support the following properties:
PROPERTY BACnet
Object_Identifier Required
Object_Name Required
Object_Type Required
Present_Value Required
Status_Flags Required
Event_State Required
Out_Of_Service Required
Units Required
Description Optional
Reliability Optional
Min_Pres_Value Optional
Minimum_Value_Timestamp Optional
Max_Pres_Value Optional
Maximum_Value_Timestamp Optional
Average_Value Optional
Instantaneous_Timestamp Proprietary
Average_Timestamp Proprietary
Max_Average_Value Proprietary
Max_Average_Timestamp Proprietary
Min_Average_Value Proprietary
Min_Average_Timestamp Proprietary
Harmonics_Row_02 Proprietary
Harmonics_Row_03 Proprietary
Harmonics_Row_04 Proprietary
PROPERTY BACnet
Harmonics_Row_05 Proprietary
Harmonics_Row_06 Proprietary
Harmonics_Row_07 Proprietary
Harmonics_Row_08 Proprietary
Harmonics_Row_09 Proprietary
Harmonics_Row_10 Proprietary
Energy_Total_Residual Proprietary
Energy_Total_Hourmeter Proprietary
Energy_Partial Proprietary
Energy_Partial_Residual Proprietary
Energy_Partial_Hourmeter Proprietary
Energy_Total_Lagging Proprietary
Energy_Total_Lagging_Res Proprietary
Energy_Total_Leading Proprietary
Energy_Total_Leading_Res Proprietary
Energy_Last_Partial Proprietary
Energy_Last_Partial_Res Proprietary
Energy_Last_Partial_Timestamp Proprietary
Multifluid_Partial Proprietary
Multifluid_Weight Proprietary
Instant_Min_Max_Reset Proprietary
Average_Min_Max_Reset Proprietary
The way the OID is assigned to an Analog Input Object (instance number) is the following:
OID = LLMM
• with LL = Load # of the device (starting at 1).
• with MM = Index of the measurement type (see Analog Input Measurement List).
For example, Analog Input with OID 204 reects Phasis/Neutral Voltage V1 of Load 2 of corresponding device.
